Scaffolding Double Front Guard Rail 73 – Galvanized Steel (W732 × H500 mm)
Integrated Front Safety Railing for Scaffolding Systems
The Double Front Guard Rail 73 is a specialized scaffolding component designed to provide complete front-edge protection. It combines both main and intermediate handrails in one unit, ensuring fast installation and maximum safety on the front side of scaffolding.
Key Features
- Double rail system (main + intermediate railing)
- Compact and strong front protection solution
- Quick mounting using half-coupler and C-profile system
- Heavy-duty galvanized steel construction
- Designed for front façade scaffolding safety
Technical Specifications
| Specification | Value |
|---|---|
| System Width | 732 mm |
| Overall Length | 760 mm |
| Overall Height | 500 mm |
| Weight | 32 kg |
| Material | Galvanized Steel |
Construction & Design
- Main structure consists of:
- Horizontal tube acting as the main front railing
- Half-coupler for secure connection to frame stand
- C-profile end for mounting on external frame stand
- Additional bent welded pipe provides:
- Integrated intermediate handrail
- Engineered for rigid and stable front protection
Functional Role in Safety System
The double front railing forms part of a complete front balustrade system, consisting of:
- Main railing (top rail)
- Intermediate railing (mid rail) (integrated in this unit)
- Toe board (front curb)
Together, they create a full safety barrier on the front side of scaffolding platforms.
Functional Advantages
- Combines two safety rails in one component
- Reduces installation time and components needed
- Ensures maximum fall protection at height
- Strong and durable for heavy-duty construction use
- Secure locking system for stable assembly
Compatibility
- Scaffold frame stands
- External frame structures
- Front curb (toe board) systems
- Standard modular scaffolding setups
Applications
- Construction and façade scaffolding
- Industrial maintenance at height
- Renovation and installation projects
- Temporary access platforms
- High-rise building works
Advantages
- Efficient 2-in-1 railing system
- Heavy-duty and long-lasting galvanized finish
- Improves safety compliance on-site
- Easy integration into existing scaffold systems
- Designed for demanding construction environments
Contact Us for Orders & Technical Support
- Email: [email protected]
- Call: +971 44058154
- WhatsApp: +971543554679
SALESBRIDGES provides complete scaffolding safety systems and accessories. Contact us today for pricing and compatibility support.
