5-Channel Light weight Cable Protector for 1.25 inch ( 3.17cm) Lines - Y/GRY
60% lighter than other leading polyurethane 5-channel cable protectors. Protects cables and hoses up to 3.18cm outside dia. With a 4534 Kg/Axle Load capacity. This modular is ideal to use in light commercial and utility application.
- Excellent quality
- Large product range
- Smart sollutions
- More information? Contact us about this product
- Add to comparison list
Lightweight Cable Protector with Cover – 5 Channels (Ø31 mm, 4.5 Ton Axle Load)
Ultra-Light Cable Protection for Events & Light Industrial Use
The Lightweight 5-Channel Cable Protector is an advanced solution for protecting cables and hoses up to Ø31 mm (1.25”) in areas with pedestrian and light vehicle traffic. Designed to be up to 75% lighter than standard models, it ensures easy handling without compromising strength.
High Strength in a Lightweight Design
Made from high-impact, non-conductive polyurethane, this protector offers excellent resistance to oil, fuel, and wear. Its snap-fit hinged lid and modular connector system allow quick installation and secure linking of multiple units.
Key Features
- Ultra-lightweight design (only 5.9 kg)
- 5 cable channels (Ø31 mm each)
- High load capacity: 4534 kg per axle
- Snap-fit hinged lid (no rod required)
- Non-conductive, impact-resistant polyurethane
- Modular connection system for multiple units
- Anti-slip tread pattern for safety
Technical Specifications
| Specification | Value |
|---|---|
| Length | 990 mm (39 in) |
| Width | 417 mm (16.44 in) |
| Height | 40 mm (1.59 in) |
| Weight | 5.9 kg (12.75 lbs) |
| Number of Channels | 5 |
| Cable Diameter | Ø 31 mm (1.25 in) |
| Material | Polyurethane |
| Color | Yellow lid / Grey base |
Load Capacity
| Load Type | Capacity |
|---|---|
| Per Tire | 2267 kg (5000 lbs) |
| Per Axle | 4534 kg (10000 lbs) |
Construction Details
- High-impact polyurethane for durability
- Non-conductive material for electrical safety
- Oil, fuel, and lubricant resistant
- Patented 5-bar tread pattern for traction
- Snap-fit hinged lid for easy cable access
- Integrated carry handle for ergonomic transport
- Gripper connector system for secure linking
Standard Delivery
- Cable protector unit with hinged lid
- Ready for immediate use
Applications
- Events and exhibitions
- Public areas and pedestrian zones
- Light commercial environments
- Utility and maintenance work
- Cable and hose protection in temporary setups
Advantages
- Extremely lightweight and easy to handle
- Fast installation and modular expansion
- High durability and chemical resistance
- Safe for pedestrian and vehicle traffic
- Protects valuable cables and hoses
Contact Us for a Quote or Consultation
- Email: [email protected]
- Call: +971 44058154
- WhatsApp: +971543554679
Protect your cables efficiently with the SALESBRIDGES lightweight cable protector system. Request your quote today.
| Brand | SalesBridges |
| Article code | SBGG5X125-Y/GRY |
| SKU | SBGG5X125-Y/GRY |
| EAN | 9501283922719 |
