4 reels mobile dispenser 1815x780xH1870mm Load 500kg
5 swivel wheels with a diameter of 160mm, including 4 with brakes. Capacity: Coils length 1540mm, diameter 300mm maximum. Load: up to 500kg Made in France 5 years warranty
- Excellent quality
- Large product range
- Smart sollutions
- More information? Contact us about this product
- Add to comparison list
ERGONOMIC MOBILE DISPENSER - 4 REELS
Durable and Ergonomic Reel Dispensing Solution
The ergonomic mobile dispenser is designed for efficient handling and dispensing of single or multiple reels in industrial and workshop environments. Built from robust steel tubes and sheet steel, it provides a strong and reliable structure for daily use while supporting loads of up to 500 kg.
Adjustable Multi-Reel Support with Smooth Mobility
This dispenser is equipped with 5 swivel wheels with a diameter of 160 mm, including 4 with brakes for secure positioning during use. The reel support tubes are mounted on bearings to facilitate smooth reel rotation and are height-adjustable in 50 mm intervals. Its fine-textured epoxy powder-coated finish, oven-polymerised at 180°C, ensures durability and a professional appearance.
Key Features
- Supports single or multiple coils up to 1540 mm in length
- Maximum load capacity of 500 kg
- 5 swivel wheels, including 4 with brakes, for easy movement and control
- Bearing-mounted reel support tubes for smoother reel rotation
- Strong steel construction with durable epoxy powder-coated finish
Technical Specifications
| Specification | Value |
|---|---|
| Length | 1815 mm |
| Width | 780 mm |
| Height | 1870 mm |
| Load Capacity | 500 kg |
| Wheel Diameter | 160 mm |
| Number of Wheels | 5 |
| Braked Wheels | 4 |
| Coil Length Capacity | Up to 1540 mm |
| Max Coil Diameter | 300 mm |
| Reel Support Tube Diameter | 40 mm |
| Reel Support Tube Thickness | 2 mm |
| Main Tube Sizes | 60 x 30 x 2 mm and 40 x 40 x 2 mm |
| Sheet Steel Thickness | 2.5 mm and 4 mm |
| Height Adjustment | 50 mm intervals |
| Finish | Fine-textured structured epoxy powder paint, oven-polymerised at 180°C |
| Color Options | Blue, Light Grey, Anthracite, Red, Yellow, White |
| Origin | France |
| Warranty | 5 Years |
| Manufacturing Origin | Made in France |
Standard Delivery
- 1 x Ergonomic Mobile Dispenser - 4 Reels
- 5 x Swivel wheels fitted to the unit, including 4 with brakes
- Adjustable bearing-mounted reel support system
Contact Us for a Quote or Consultation
Email: [email protected]
Call: +971 44058154
WhatsApp: +971543554679
Enhance your operations with the reliable and cost-effective solution from SALESBRIDGES. Request your quote today.
Made in France
| Brand | Salesbridges |
| Article code | SB010080421 |
| SKU | SB010080421 |
| EAN | 9507453629976 |
