Roll container trolley for plastic crates Rollbox series 2 columns

Product description

Roll Container Trolley for Plastic Crates – Rollbox Series

Flexible Crate Transport System for Warehouses and Production Areas

The Rollbox Series is a versatile roll container trolley designed for safe and efficient transport of plastic crates in warehouses, production facilities, food handling areas, and logistics operations. Available in 1, 2, or 3-column configurations with multiple level options, it is ideal for organizing and moving Euro containers with ease.

Ergonomic, Adjustable, and Built for Daily Use

Each Rollbox trolley is equipped with container support rails featuring tilt adjustment for more ergonomic loading and unloading. The levels can be adjusted in 50 mm steps, while the sturdy steel construction, epoxy powder-coated finish, and smooth non-marking castors ensure long-term durability and reliable performance in demanding environments.

Key Features

Available in 1, 2, or 3-column models with 4 or 6 levels
Support rails with tilt adjustment: 0°, 5°, 10°, 15° forward and backward
Height adjustment in 50 mm steps
Strong steel construction with epoxy powder-coated finish
300 kg load capacity, upgradeable to 500 kg on 2 and 3-column models with 2 additional castors

Technical Specifications

Specification	Value
Suitable Crate Sizes	60 x 40 cm or 40 x 30 cm
Standard Load Capacity	300 kg
Maximum Load Capacity	Up to 500 kg with 2 additional castors on 2 and 3-column models
Level Adjustment	50 mm steps
Rail Tilt Adjustment	0°, 5°, 10°, 15° forward and backward
Frame Material	Folded sheet steel, thickness 10/10th
Base Material	Folded sheet steel 20/10th and 10/10th
Finish	Epoxy powder coating, oven polymerized at 180°C
Castors	4 swivel castors with plate, 2 with locks
Wheel Material	Thermoplastic rubber, gray non-marking
Wheel Diameter	100 mm
Handles	Supplied with 2 handles
Delivery Condition	Supplied flat packed, mounting with screws

Available Models

P/N	Width (mm)	Depth (mm)	Height (mm)	Model
SBRB0020	510	610	1235	1 column, 4 levels – 4 containers 60 x 40 cm
SBRB0021	970	610	1235	2 columns, 4 levels – 8 containers 60 x 40 cm
SBRB0022	1430	610	1235	3 columns, 4 levels – 12 containers 60 x 40 cm
SBRB0023	510	610	1725	1 column, 6 levels – 6 containers 60 x 40 cm
SBRB0024	970	610	1725	2 columns, 6 levels – 12 containers 60 x 40 cm
SBRB0025	1430	610	1725	3 columns, 6 levels – 18 containers 60 x 40 cm
SBRB0026	710	810	1235	1 column, 4 levels – 8 containers 60 x 40 cm
SBRB0027	1370	810	1235	2 columns, 4 levels – 16 containers 60 x 40 cm
SBRB0028	710	810	1725	1 column, 6 levels – 12 containers 60 x 40 cm
SBRB0029	1370	810	1725	2 columns, 6 levels – 24 containers 60 x 40 cm
