Manual Stacker 1000kg Capacity, 2500mm Lift Height – Duplex 2-Stage Mast
EB-1025 manual stacker with 1000kg capacity and 2500mm lifting height. Features duplex 2-stage mast, foot and hand pump, 1150mm forks, nylon wheels and reinforced chassis. Available across the GCC from SalesBridges.
- Excellent quality
- Large product range
- Smart sollutions
- More information? Contact us about this product
- Add to comparison list
EB-1025 Manual Stacker – 1000kg Capacity with 2500mm Lift Height
The EB-1025 Manual Stacker is a durable and efficient material handling solution for lifting, transporting and stacking palletized loads in warehouses, retail stockrooms, manufacturing facilities and logistics operations. With a lifting capacity of 1000kg and a maximum lift height of 2500mm, this manual hydraulic stacker provides dependable performance for medium-duty lifting requirements.
Designed with a welded and strengthened chassis, the EB-1025 stacker offers excellent stability when handling heavy loads. Its duplex, 2-stage lifting mast is manufactured from strong C-section steel profiles and uses dual lifting chains with a single lifting cylinder for controlled and reliable vertical movement.
The stacker is operated using either a foot pump or hand pump, allowing operators to select the most convenient lifting method. Nylon steering and fork wheels support smooth movement, reduce floor marking and assist with maneuverability in confined warehouse aisles.
Key Features
- Maximum load capacity of 1000kg
- Lifting range from 85mm to 2500mm
- Duplex 2-stage lifting mast
- Welded and reinforced chassis for improved strength and stability
- C-section mast profiles for reliable lifting performance
- Dual lifting chains with a single hydraulic lifting cylinder
- Foot pump and hand pump operation
- 1150mm fork length for standard pallet handling
- Nylon steering wheels and nylon fork wheels
- Compact turning radius of 1350mm
- Suitable for warehouse, storage, production and distribution environments
- Durable manual alternative to electric stackers for cost-effective material handling
- Delivery available across the GCC area
Benefits of the EB-1025 Manual Hydraulic Stacker
The EB-1025 is designed for businesses that require a practical, low-maintenance solution for lifting pallets to elevated storage locations. As a manually operated stacker, it does not require batteries or electrical charging infrastructure, making it suitable for a wide range of indoor material handling applications.
Its 2500mm lift height enables efficient stacking and placement of loads on racking systems, while the narrow overall width supports movement through standard warehouse aisles. The high-quality nylon wheels provide smooth travel on suitable flat surfaces.
Typical Applications
- Warehouses and distribution centres
- Stockrooms and retail back-of-house areas
- Manufacturing and assembly lines
- Packaging and loading areas
- Spare-parts storage facilities
- Logistics and freight operations
- Pallet lifting and racking applications
Technical Specifications
| Specification | Details |
|---|---|
| Model | EB-1025 |
| Product Type | Manual hydraulic stacker |
| Load Capacity | 1000kg |
| Lifting Height | 85–2500mm |
| Mast Type | Duplex, 2-stage lifting mast |
| Load Centre | 460mm |
| Overall Dimensions (L × W × H) | 1600 × 760 × 1840mm |
| Fork Length | 1150mm |
| Fork Width – Total | 550mm |
| Fork Width – Individual Fork | 160mm |
| Product Weight | 310kg |
| Steering Wheel Material | Nylon |
| Steering Wheel Size | Ø150 × 40mm |
| Fork Wheel Material | Nylon |
| Fork Wheel Size | Ø80 × 70mm, single |
| Turning Radius | 1350mm |
| Lifting Speed | 12.5mm per stroke |
| Pump Operation | Foot pump and hand pump |
| Chassis Construction | Welded and strengthened steel chassis |
| Mast Construction | C-section profiles with dual chains and single lifting cylinder |
Order the EB-1025 Manual Stacker from SalesBridges
Upgrade your warehouse handling process with the EB-1025 1000kg manual stacker. This robust lifting equipment is ideal for safely raising and stacking standard pallets up to 2500mm.
For RFQ, availability, bulk pricing or product support, contact SalesBridges:
Email: [email protected]
Phone: +971 44058154
SalesBridges delivers manual stackers, warehouse equipment and material handling solutions across the GCC area.
